Compatible with most cleaning products in pH range 4.5 to 8.5 or 2 to 12 with additional option
Internally pressurised, fully enclosed structure
NSF H1 food grade lubricant with no loss in operating performance
No warmup routine required for food grade lubricants
Absolute encoders - no backup batteries to replace
Designed for use in wet and humid environments and to resist corrosion even under extreme conditions
Surfaces are extra smooth and rounded and rotating joints widened to eliminate bacteria trap zones and facilitate water runoff
Cables and pneumatic piping runs internally from the foot to the forearm making wash down easier, eliminating bacteria traps and ensuring the arm has maximum freedom of movement
Small footprint and wide work envelope means arm can be installed into tighter places
Cables and pneumatics are connected under the foot providing optimal protection against water ingress
Multiple mounting options provide flexibility in production line design
Reduced maintenance and long life through use of Staubli’s own reduction gear systems
